HPB, 50-1000 Ton, Clamp Rail Type Synchronous Pushing Hydraulic System
-
Acting Way Double Acting Capacity 50-1000 ton Country of Origin China Manufacturer SAIVS Minimum Order 1 Piece Model HPB-250 | HPB-400 | HPB-600 | HPB-1000 Stroke 150/200/400/500 mm Structure Piston Type Working Pressure 700 bar/10000 PSI Other Parameters Cylinder Area: 78.5-1250 cm² - HLA , Double Acting，PLC Synchronous Lifting Systems HLD, Multi-point, PLC Synchronous Lifting Systems HLC, Double Acting, PLC Synchronous Lifting Systems HLB, Single Acting, PLC Synchronous Lifting Systems HLE, Intelligent quantitative, Synchronous Lifting Systems HPA, 60-110 Ton, Clamp Rail Type Synchronous Pushing Hydraulic System HPB, 50-1000 Ton, Clamp Rail Type Synchronous Pushing Hydraulic System HPC, 100-600 Ton, Clamp Rail Type Synchronous Pushing Hydraulic System HPD, 100-200 Ton, Clamp Rail Type Synchronous Pushing Hydraulic System SCM Series Hydraulic Pusher
Description
Product Line: Industrial Tools
Customizable with special requirement
The innovative walking type synchronous pushing Hydraulic Equipment offers advanced features, including high-speed, stable pushing, ultra-high pressure hydraulic technoLogy, and precise speed control. Its ability to adjust the vertical supporting force and bridge attitude ensures safe and reliable construction of composite structure bridges. The equipment's integrated design and versatile functions make it well-suited for pushing various types of steel structures, meeting the demands of modern bridge construction.
Applications
|
|
Image Gallery
Details
Series Comparison
| Model | Capacity(T) | Stroke(mm) | Working Pressure(bar) | Cylinder Area(cm2) | |
| HPB-250 | Vertical(Z) | 250 | 200 | 700 | 363 |
| Horizontal(X) | 50 | 150 | 700 | 78.5 | |
| Longitudinal(Y) | 50 | 500 | 700 | 78.5 | |
| HPB-400 | Vertical(Z) | 400 | 200 | 700 | 572.3 |
| Horizontal(X) | 60 | 150 | 700 | 95 | |
| Longitudinal(Y) | 60 | 400 | 700 | 95 | |
| HPB-600 | Vertical(Z) | 600 | 200 | 700 | 855 |
| Horizontal(X) | 100 | 150 | 700 | 133 | |
| Longitudinal(Y) | 100 | 400 | 700 | 133 | |
| HPB-1000 | Vertical(Z) | 1000 | 200 | 700 | 1250 |
| Horizontal(X) | 200 | 150 | 700 | 283 | |
| Longitudinal(Y) | 200 | 400 | 700 | 283 | |
