P80 Two Speed,Single-acting Hydraulic Steel Hand Pump
-
Brand Name Replacement Enerpac's P80 Country of Origin China Manufacturer SAIVS Max.Operating Pressure 700 bar Minimum Order 1Piece Model P80 Pressure Rating 1st Stage 25bar/348.1 psi Pressure Rating 2nd Stage 700bar/10000 psi Pump Type Double Speed Usable Oil Capacity 2200cm³ Used with Cylinder Single-Acting Weight 10.9 kg - Air Driven Hydraulic Torque Wrench Pump SPA Series Ultra High Pressure Electric Pumps - PTE Series 700 bar/10000PSI Electric Hydraulic Pump HP1000DMIN, Two Speed 67.7 in³ Usable Oil,Hydraulic Sealed Hand Pump P391, Single Speed, Lightweight Hydraulic Hand Pump P142, Two Speed, Lightweight Hydraulic Hand Pump P80 Two Speed,Single-acting Hydraulic Steel Hand Pump P84 Two Speed, Hydraulic Steel Hand Pump,Double-Acting Cylinders PAT Series Foot Air Hydraulic Pumps JEA2-9,Gasoline Engine Hydraulics Wrench Pump
Description
Model:P80
Product Line: Industrial Tools
Customizable with special requirement
SAIVS offers high-pressure, two-speed manual hydraulic Hand Pumps in a robust,
lightweight steel design. Ideal for portability and demanding environments,
the pumps provide efficient operation with high flow for filling and high pressure for power.
Image Gallery
Dimensions
P80 Two Speed,Single-acting Hydraulic Steel Hand Pump
| Model Number | A | B | C | D | E | F | H | J | L | M | N | P | Q | R | S | T |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| P80 | 425 | 539 | 25 | 44 | 54 | - | 527 | 29 | 174 | 19 | 146 | 121 | - | 21 | 8 | 67 |
| Model Number | Pump Type | Usable Oil Capacity (cm3) | Pressure Rating (bar) | Oil Displacement per Stroke (cm3) | Max. Handle Effort (kg) | Piston Stroke (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| P80 | Two Speed | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 47 | 25.4 | 10.9 |
| Model Number | Pump Type | Usable Oil Capacity (cm3) | Pressure Rating (bar) | Oil Displacement per Stroke (cm3) | Max. Handle Effort (kg) | Piston Stroke (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| P392 | Double speed | 655 | 1st stage: 25 2nd stage: 700 | 1st stage: 15 2nd stage: 2.62 | 50 | 20.6 | 5.9 |
| P80 | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 47 | 25.4 | 10.9 | |
| P84 | 2200 | 1st stage: 25 2nd stage: 700 | 1st stage: 16.22 2nd stage: 2.46 | 49 | 25.4 | 13.2 | |
| P462 | 7423 | 1st stage: 14 2nd stage: 700 | 1st stage: 26.20 2nd stage: 4.75 | 49 | 38.1 | 27 | |
| P464 | 7423 | 1st stage: 14 2nd stage: 700 | 1st stage: 26.20 2nd stage: 4.75 | 49 | 38.1 | 27.7 |
