Plug-In Torque Wrench,9x12,14x18mm,DA-1 Series

Accuracy ±4%
Brand SAIVS
Customized OEM,ODM
L/W/H(mm) 208-653/28-45/28-42
Minimum Order 1Piece
Model Number DA-1
Place of Origin China
Specification 9x12,14x18
Torque range(Nm) 1-500Nm
Weight(kg) 0.4-1.89
150-500Nm,Pneumatic Torque Wrench,SFW5A 1800-6000Nm,Pneumatic Torque Wrench,SFW60A 240-800Nm,Pneumatic Torque Wrench,SFW8A 2400-8000Nm,Pneumatic Torque Wrench,SFW80A 3000-10000Nm,Pneumatic Torque Wrench,SFW100A 3600-12000Nm,Pneumatic Torque Wrench,SFW120A 405-1350 Nm,Pneumatic Torque Wrench,SFW14A 600-2000Nm,Pneumatic Torque Wrench,SFW20A 80-300Nm,Pneumatic Torque Wrench,SFW3A Pneumatic Torque Wrench SFW-A Series

Description

The Torque Wrench body is made of

durable metal structure, with ±4% torque error.

The plastic handle is made of aluminum

alloy for oil resistance, anti-slip, and durability.

The alloy steel pipe has a permanent

torque scale for easy reading in metric and English systems.

It has interchangeable heads in sizes

of 9x12 and 14x18 concave square heads.

Each torque wrench has a unique product identification code.

Image Gallery

Dimensions

DA-1 Type Plug-in torque wrench
Model Number	Torque range		Specifications	Fine Scale/N.m		Length/mm	Width/mm	Height/mm	Weight/Kg
Model Number	N.m	Lbf.ft	Specifications	N.m	Lbf.ft	Length/mm	Width/mm	Height/mm	Weight/Kg
DA02601	1-5	2-9	9x12	0.05	0.067	208	28	28	0.4
DA02602	2-12	2-9	9x12	0.1	0.074	208	34	30	0.4
DA02603	4-20	3-15	9x12	0.2	0.147	208	34	30	0.45
DA02604	5-25	4-19	9x12	0.2	0.147	208	34	30	0.45
DA02605	6-30	5-23	9x12	0.2	0.147	268	34	30	0.48
DA02606	10-60	9-46	9x12	0.5	0.369	268	41	34	0.8
DA02607	10-100	7-75	9x12	0.5	0.369	388	41	34	0.81
DA02608	20-100	15-75	9x12	0.5	0.369	388	41	34	0.81
DA02609	25-125	20-94	9x12	0.5	0.369	388	41	34	0.81
DA02610	40-200	30-150	14x18	1.0	0.738	448	41	34	0.87
DA02611	20-210	15-155	14x18	1.0	0.738	448	41	34	0.87
DA02612	60-300	45-226	14x18	1.0	0.738	603	45	42	1.87
DA02613	65-335	50-250	14x18	1.0	0.738	603	45	42	1.87
DA02614	65-350	50-260	14x18	1.0	0.738	603	45	42	1.87
DA02615	80-400	60-300	14x18	2.0	1.475	653	45	42	1.89
DA02616	100-500	80-376	14x18	2.0	1.475	653	45	42	1.89

Details

Application

Installing pipeline components

Securing structural steel connections

Aircraft maintenance

Shipbuilding and marine applications

Composite materials fabrication

Wind tunnel testing

Building and testing prototype vehicles

Video

Literature

1.Working principle of manual torque wrenches

2.Repair Methods For Digital Torque Wrench

3.How Often Should I Calibrate My Torque Wrench

4.Types of Manual Torque Wrenches

5.Precautions for using preset torque wrenches

6.Basic knowledge of dial torque wrench

FAQs

How is the accuracy and reliability of a Plug-In Torque Wrench ensured?

The accuracy and reliability of a Plug-In Torque Wrench are ensured through regular calibration,

where its readings are compared to a known standard to check for any deviations or errors.

Calibration helps maintain accurate torque measurements and ensures the wrench performs within acceptable limits.

How can one determine if a Plug-In Torque Wrench has reached the set torque value?

Plug-In Torque Wrenches typically indicate the achievement of a set torque

value through an audible click or sound,or visual indicators such as a dial or digital display.

These indicators alert the user when the desired torque has been reached, ensuring proper tightening.

PROVIDING EXCELLENT SOLUTIONS BY SAIVS™

if you are looking for factory manufacturers and suppliers of Plug-In Torque Wrench,9x12,14x18mm,DA-1 Series,

choose SAIVS TOOL because of the high quality, variety of choices, low price and fast delivery.

you can easily find the best Plug-In Torque Wrench,9x12,14x18mm,DA-1 Series solution here!

Speak to one of our experts today to learn more about our Plug-In Torque Wrench,9x12,14x18mm,DA-1 Series products solutions.
