3/4,1/2 Inch Preset Torque Wrench,TG Series
-
Accuracy ±4% Brand SAIVS Customized OEM,ODM Driver(inch) 3/8，1/2，3/4 ,1/4 , 3/2 , 1 L/W/H(mm) 305-3250/33-118/30-100 Minimum Order 1Piece Model Number TG Place of Origin China Torque range(Nm) 1-6000Nm Weight(kg) 0.55-55 - 150-500Nm,Pneumatic Torque Wrench,SFW5A 1800-6000Nm,Pneumatic Torque Wrench,SFW60A 240-800Nm,Pneumatic Torque Wrench,SFW8A 2400-8000Nm,Pneumatic Torque Wrench,SFW80A 3000-10000Nm,Pneumatic Torque Wrench,SFW100A 3600-12000Nm,Pneumatic Torque Wrench,SFW120A 405-1350 Nm,Pneumatic Torque Wrench,SFW14A 600-2000Nm,Pneumatic Torque Wrench,SFW20A 80-300Nm,Pneumatic Torque Wrench,SFW3A Pneumatic Torque Wrench SFW-A Series
Description
Accuracy: Level 4, ensuring highly precise torque measurements with minimal deviation.
This high level of accuracy guarantees that torque tool delivers
consistent and reliable results across a wide range of applications.
Error range: Within ±4%, providing a tight tolerance for error in torque measurements.
It minimizes the risk of overtightening or undertightening fasteners,
ensuring optimal Performance and safety.
Component: The torque tool is constructed using high-quality
alloy steel, known for its exceptional strength and durability.
This choice of material ensures that the tool can withstand
demanding work environments and heavy use without compromising its accuracy or longevity.
Ratchet head: The torque tool features a ratchet head equipped with a bidirectional mechanism,
allowing for easy operation in both tightening and loosening directions.
This feature enhances versatility by accommodating various
tasks where both clockwise and counterclockwise torquing is required.
Image Gallery
Dimensions
| TG type preset torque wrench | ||||||||
| Model Number | Torque range | Driver/inch | Length/mm | Width/mm | Height/mm | Weight/kg | Fine Scale/N.m | Ratchet Teeth |
| TGK 19301 | 1-5 | 1/4" | 305 | 33 | 30 | 0.55 | 0.25 | 22 |
| TGK 19302 | 2-10 | 1/4" | 305 | 33 | 30 | 0.55 | 0.25 | 22 |
| TGK 19303 | 5-25 | 3/8" | 305 | 33 | 30 | 0.55 | 0.25 | 22 |
| TGK 19304 | 8-40 | 3/8" | 305 | 33 | 31 | 0.525 | 0.5 | 22 |
| TGK 19305 | 10-50 | 1/2" | 415 | 40 | 40 | 0.99 | 1 | 22 |
| TGK 19306 | 20-100 | 1/2" | 415 | 40 | 40 | 0.99 | 1 | 22 |
| TGK 19307 | 40-200 | 1/2" | 635 | 48 | 48 | 2.165 | 7.5 | 22 |
| TGK 19308 | 60-300 | 1/2".3/4" | 635 | 48 | 48 | 2.165 | 7.5 | 19 |
| TGK 19309 | 150-450 | 3/4" | 685 | 48 | 52 | 2.25 | 10 | 19 |
| TGK 19310 | 100-500 | 3/4" | 685 | 48 | 52 | 2.25 | 10 | 19 |
| TGK 19311 | 140-760 | 3/4" | 835 | 55 | 58 | 4.19 | 10 | 18 |
| TGK 19312 | 280-760 | 3/4" | 835 | 55 | 58 | 4.19 | 10 | 18 |
| TGK 19313* | 200-1000 | 3/4".1" | 900+570（1340） | 58 | 58 | 4.4+1.66 | 12.5 | 18 |
| TGK 19314* | 500-1500 | 1" | 1010+570（1450） | 69 | 68 | 6.81+1.94 | 25 | 15 |
| TGK 19315* | 750-2000 | 1" | 1010+870（1750） | 69 | 68 | 6.81+3.00 | 25 | 15 |
| TGK 19316* | 1000-3000 | 1" | 1400+1000（2140） | 84 | 76 | 14.6+6.10 | 25 | 15 |
| TGK 19317* | 2000-4000 | 3/2" | 1650+1250（2640） | 100 | 90 | 25+9.5 | 50 | 15 |
| TGK 19318* | 3000-6000 | 3/2" | 2005+1500（3250） | 118 | 100 | 41+14.00 | 100 | 15 |
Details
Application
Securing fasteners in woodworking
Installing plumbing fixtures
Maintaining firearms
Installing door hardware
Attaching vehicle suspension components
Erecting wind turbines
Research and development in various industries
Video
Literature
- 1.Working principle of manual torque wrenches
- 2.Repair Methods For Digital Torque Wrench
- 3.How Often Should I Calibrate My Torque Wrench
- 4.Types of Manual Torque Wrenches
- 5.Precautions for using preset torque wrenches
- 6.Basic knowledge of dial torque wrench
FAQs
What is the difference between a preset and adjustable torque wrench?
The main difference between preset and adjustable torque wrenches is that preset
wrenches have a fixed torque setting that cannot be adjusted by the user, while
adjustable wrenches allow the user to adjust the torque setting within a specified range.
Preset wrenches are simpler to use and less expensive than adjustable ones.
However, adjustable wrenches offer more flexibility for a wide range of applications
that require different torque values, and they require more careful adjustment to
ensure the correct torque value is achieved. Ultimately, the choice between preset
and adjustable wrenches depends on the application requirements and user preferences.
What is a preset type torque wrench?
A preset type torque wrench is a specialized tool designed to apply a specific amount of torque to a fastener.
Unlike adjustable torque wrenches that allow users to set different torque values, a preset torque
wrench comes with a fixed torque setting determined by the manufacturer. These wrenches are commonly
used in assembly lines or situations where consistent and precise torque application is required.
